Clear Window Dry Bag Materials
A clear window on a dry bag is the hardest single component to specify, because it has to be transparent, weldable to the shell, flexible at low temperature and stable under UV for years at the same time. Clear PVC film at 0.4 mm transmits about 88% of visible light and welds at 27.12 MHz with almost no effort, but it starts to yellow after roughly 400 hours of accelerated UV and stiffens near minus 15 °C. Clear TPU film transmits 90 to 92%, survives a bend test near minus 35 °C, and costs two to three times as much per square metre.
This guide compares the film families used in commercial window panels, explains why windows yellow and go sticky, sets out what a weld around a window perimeter actually has to hold, and gives the acceptance tests worth running before you approve a sample. The numbers come from real panel work: 12 x 18 cm windows, 60 cm of weld perimeter, 500-hour QUV runs and Shore A hardness checks. Read the comparison tables first, then decide whether the window is a functional panel or a decoration, because that answer drives the whole material choice.
- What a clear window actually has to survive
- The four window films used in production
- Why windows yellow and what the numbers mean
- Cold crack and the winter packing test
- Scratch, haze and keeping the window readable
- Welding a window into a shell that flexes
- Thickness: the trade between clarity and strength
- Plasticiser migration and the sticky-window failure
- Placement: where a window survives and where it does not
- Acceptance tests worth running on a windowed sample
- Cleaning a clear panel without ruining it
- End of life: what a window does to recyclability
- Specifying a window panel: the checklist
What a clear window actually has to survive
A window is asked to do five incompatible jobs. It must let you read the contents without opening the bag, which means high light transmission and low haze. It must stay attached to a shell that flexes, folds and gets sat on. It must stay clear after months of sun. It must not crack when the bag is packed at minus 10 °C on a winter trip. And it must not make the bag harder to recycle than it already is.
Most failures come from treating the window as a decorative trim. It is not: it is the weakest area of the bag per unit of area, because the film is thinner than the shell, the weld around it is a long continuous seam, and any loss of clarity destroys the only function the panel has. Start the specification from the environment, not from the look.
The four window films used in production
Clear PVC remains the default because it is cheap, soft and welds beautifully with radio-frequency energy at 27.12 MHz. Its weaknesses are structural: the plasticiser that makes it flexible is not chemically bound, so it migrates out over time, and the film yellows as the polymer degrades under UV. Clear TPU carries no plasticiser, welds by hot wedge or hot air rather than RF, and holds flexibility far longer.
Aliphatic TPU is the premium option and the only one that stays genuinely clear after years of sun, because it lacks the aromatic groups that absorb UV and turn yellow. EVA film is soft and cheap but hazy and poor against abrasion. A PET or PU laminate gives glass-like clarity and high stiffness, which sounds good and performs badly on a bag that rolls.
| Film | Light transmission | Flex at low temperature | Weld method | Yellowing risk |
|---|---|---|---|---|
| Clear PVC, 0.4 mm | 86-88% | Stiff near -15 °C | RF, 27.12 MHz | High after 400 h UV |
| Aromatic TPU, 0.4 mm | 90-92% | Flexible to -35 °C | Hot wedge, hot air | Moderate |
| Aliphatic TPU, 0.4 mm | 91-93% | Flexible to -40 °C | Hot wedge, hot air | Low |
| EVA film, 0.5 mm | 80-85% | Flexible to -25 °C | RF, limited | Moderate, hazes |
| PET and PU laminate | 92-94% | Cracks below -5 °C | Adhesive, hot press | Low, but delaminates |
Why windows yellow and what the numbers mean
Yellowing is a chemical change, not a surface stain. Aromatic TPU and PVC both contain structures that absorb ultraviolet energy and convert into chromophores, which show as a yellow cast that deepens with dose. Accelerated testing under fluorescent UV lamps, described in ISO 4892-3, gives a comparable number: 500 hours at 340 nm and 0.76 W per square metre is loosely equivalent to several months of subtropical sun.
The practical target is a colour shift of less than three units on the CIE delta E scale after 300 hours, and no measurable haze gain after 500 hours. Aromatic TPU typically moves four to six units over that dose, which is visible on a black bag but rarely objectionable. PVC moves further and also loses plasticiser at the same time, so it yellows and stiffens together, which is the combination that leads to cracking at the fold.
| Condition | Accelerated hours | Colour shift | What the panel looks like |
|---|---|---|---|
| Subtropical summer, one season | 300 h | Delta E 3-4 | Slight cream cast, still readable |
| Two seasons on a boat | 600 h | Delta E 5-7 | Amber cast, contents hard to identify |
| Desert or high-altitude use | 900 h | Delta E 8-12 | Brown cast, haze rising |
| Indoor retail storage | 50 h | Delta E under 1 | No visible change |
Cold crack and the winter packing test
Cold behaviour separates the films more sharply than UV does. Bend tests on coated and laminated fabrics, run to the method published by ASTM, put clear PVC with a general-purpose plasticiser near minus 15 °C before the first crack appears, while a polyester-based TPU film still passes at minus 35 °C. A winter paddler rolling a bag closed at minus 12 °C sits right on the PVC boundary.
This is why a bag sold into Nordic, Canadian or alpine markets should never use a generalised clear PVC window. The failure is sudden rather than gradual: the panel looks fine at room temperature, then the fold line develops a white stress mark and splits the first time it is rolled in the cold. Pair the window choice with the shell guidance in our cold crack notes for TPU.
Scratch, haze and keeping the window readable
Clarity is not only a material property; it is a maintenance outcome. Taber abrasion testing with CS-10 wheels at 500 g load, run under the abrasion methods published by ISO, shows the gap clearly: a hard-coated TPU panel gains about 4% haze after 1,000 cycles, while an untreated PVC panel gains 12 to 18% over the same run and starts to look frosted.
Surface hardness is the lever. Softer films feel nicer and scratch worse; a Shore A 85 panel resists a fingernail but still flexes, whereas a Shore A 95 panel resists abrasion and starts to crease at the fold. For a bag that will be rolled daily, specify Shore A 85 to 90 and accept that the panel needs gentle cleaning. Sand is the real enemy: one gritty wipe with a dry cloth puts a permanent arc of fine scratches into any clear film.
Welding a window into a shell that flexes
The weld is where most windowed bags fail, and the reason is almost always material mismatch. PVC welds to PVC by dielectric heating because the polar molecules respond to the radio-frequency field; TPU does not heat the same way and needs conducted heat from a hot wedge or hot air nozzle. Trying to RF weld a TPU window into a PVC shell, or the reverse, produces a bond that looks fine and peels at 40 to 60 N per 50 mm.
Geometry matters as much as method. A 12 x 18 cm window has 60 cm of weld perimeter, and that perimeter is 60 cm of continuous leak path built into the bag. Any section where the weld temperature drops below the film fusion point becomes a capillary channel. Target a peel strength of at least 150 N per 50 mm on TPU and 120 N per 50 mm on PVC, and 100% inspection of the perimeter rather than spot checks.
| Window size | Weld perimeter | Added leak path | Method | Target peel strength |
|---|---|---|---|---|
| 8 x 10 cm | 36 cm | Low | RF or hot wedge | 150 N per 50 mm |
| 12 x 18 cm | 60 cm | Moderate | Hot wedge, TPU | 150 N per 50 mm |
| 18 x 24 cm | 84 cm | High | Hot wedge, double pass | 170 N per 50 mm |
| Full-width strip, 30 x 8 cm | 76 cm | High at corners | RF, radiused corners | 120 N per 50 mm |
Thickness: the trade between clarity and strength
Thicker film is stronger and hazier. A 0.3 mm clear TPU panel transmits about 92% and takes a fingernail scratch easily; the same polymer at 0.6 mm transmits 89%, resists abrasion noticeably better, and adds about 55 g to a 20L bag. Above 0.6 mm the panel stops draping with the shell, which means the surrounding weld has to absorb a stiffness step, and that step is where fatigue cracks begin.
The practical sweet spot for a bag that gets rolled is 0.4 to 0.5 mm, matched to the shell film thickness within about 0.1 mm. Matching thickness is more important than absolute thickness: a 0.5 mm window in a 0.3 mm shell creates a stiff island that concentrates every fold into the 5 mm of weld around it. Our notes on 0.3 mm versus 0.5 mm film cover the same trade for the shell itself.
Plasticiser migration and the sticky-window failure
The most common long-term complaint about a PVC window is not that it cracks but that it goes sticky and cloudy at the same time. The plasticiser that keeps PVC flexible is a physical additive, not a bound part of the polymer, so it slowly migrates to the surface, where it picks up dust and turns the panel tacky. Over two to three years the film also shrinks by 1 to 2%, which puts permanent tension into the weld.
Migration accelerates with heat. A bag stored in a car boot that reaches 60 °C on a summer afternoon loses plasticiser several times faster than the same bag stored indoors, and the loss is irreversible. TPU has no plasticiser to lose, which is the single strongest argument for it on any bag that will live in a hot climate, on a boat, or behind the rear screen of a vehicle.
Placement: where a window survives and where it does not
Place a window where the shell stays flat and away from the fold. The lower third of a front or side panel is the safest zone: it is visible when the bag sits on the ground, it is not part of the roll, and it takes less abrasion than a base or a corner. The worst position is across the fold line, where the panel is bent 180 degrees three times every time the bag is closed.
Radiused corners are not cosmetic either. A square corner concentrates peel stress at a single point and is the origin of most window leaks; a 10 mm radius spreads that load around the curve. If the design allows it, run the window as a horizontal strip rather than a tall rectangle, because the strip keeps the weld away from the vertical creases that form when a loaded bag is squeezed into a hatch.
Acceptance tests worth running on a windowed sample
Four tests catch nearly every window problem before a bulk order ships. Run a 300-hour QUV exposure and measure delta E and haze. Run a low-temperature bend at the minimum service temperature of the market. Run a 30-minute immersion at one metre on three samples with the window submerged. Then run a peel test on cut strips from the actual weld, not from a test coupon welded separately.
Record the results as pass bands, not single numbers, because film varies between lots. A window that welds to 180 N per 50 mm in one lot and 140 N in the next is still acceptable if your minimum is 120 N, but you need to know the spread before you commit to 20,000 pieces. The broader inspection framework is set out in our quality control guide for waterproof bags.
| Test | Method | Pass band | Failure mode it catches |
|---|---|---|---|
| UV stability | ISO 4892-3, 300 h | Delta E under 3 | Yellowing in season one |
| Low-temperature bend | ASTM low-temperature bend | No crack at -25 °C | Winter fold splitting |
| Immersion | 30 min at 1 m, 3 samples | Zero internal moisture | Perimeter capillary leak |
| Weld peel | Strip peel, 50 mm | 120-180 N | Cold weld sections |
| Haze after abrasion | Taber CS-10, 1,000 cycles | Under 8% gain | Frosting from sand contact |
Cleaning a clear panel without ruining it
Clean windows with the same rule you use for sunglasses: rinse first, wipe second. Grit left on the surface becomes an abrasive the moment a cloth moves across it, and one dry wipe on a salty panel is enough to put a permanent arc of fine scratches into a 0.4 mm film. Rinse with fresh water, then wipe with a wet microfibre cloth and let it air dry.
Avoid solvents completely. Alcohol, acetone and most screen cleaners attack the surface of both PVC and TPU, leaving a milky bloom that cannot be polished out. Sunscreen is the other quiet killer: oxybenzone and similar filters soften TPU surfaces on contact, so wipe the panel after a beach day rather than waiting for the end of a trip.
End of life: what a window does to recyclability
A windowed bag is harder to recycle than a single-polymer bag, and a PVC window in a TPU shell is the worst combination of all. Mechanical recycling needs a reasonably pure stream; a PVC-contaminated TPU stream gels and blackens above about 180 °C and produces material that nobody will buy. Keeping the window and the shell in the same polymer family preserves most of the recycling value.
The practical rule for a range that claims any recyclability is simple: TPU shell, TPU window, welded rather than adhesive-bonded, and a window area kept under about 8% of the total surface. If a design needs a PVC window for cost reasons, isolate it as a removable panel so the two polymers can be separated at end of life. More on the wider picture is in how recyclable dry bags are.
Specifying a window panel: the checklist
- Decide the job first: identification panel or decoration, because decoration can be printed and identification cannot.
- Match the window polymer to the shell polymer; never ask a PVC panel to weld into a TPU body.
- Fix thickness at 0.4 to 0.5 mm and keep the window within 0.1 mm of the shell film.
- Set a UV target: delta E under 3 after 300 hours of ISO 4892-3 exposure.
- Set a cold target: no cracking at the coldest packing temperature of the target market.
- Radius every window corner at 10 mm and keep the panel off the roll fold line.
- Require 100% perimeter inspection and a peel test from production welds, not from coupons.
- Compare the finished spec against the full product line before signing off.
When a window panel is part of a branded programme rather than a single bag, the same checklist turns into a short specification sheet: polymer family, thickness, transmission, haze, weld method, peel target and UV band. Our production partner has built waterproof bags since 2014 in an SGS-verified 4,950 m2 facility running seven production lines and 149 machines, with sampling in 6 to 10 working days and bulk in 35 to 50 days.
Two related decisions usually follow. If the panel exists to carry a mark, the placement and print rules in window branding on dry bags matter more than the polymer. If the real question is the shell film itself rather than the window, start with TPU versus PVC dry bag fabric, then narrow the film weight using the UV-stabilised fabric notes.
Frequently asked questions
Q1. What material is a clear dry bag window made from?
Most are clear PVC film at 0.3 to 0.5 mm because it welds easily and costs least. Better bags use clear TPU film, which carries no plasticiser, stays flexible to about minus 35 °C and yellows far more slowly, at two to three times the material cost.
Q2. Why does my dry bag window turn yellow?
Ultraviolet energy changes the polymer structure and creates light-absorbing groups that read as yellow. Aromatic TPU and PVC both do it; aliphatic TPU largely does not. Standard clear PVC shows visible yellowing after about 400 hours of accelerated UV exposure.
Q3. Are clear windows as waterproof as the rest of the bag?
The film is, but the weld around it is the weak point. A 12 x 18 cm window adds 60 cm of continuous seam, so the perimeter needs 100% inspection and a peel target of at least 150 N per 50 mm on TPU or 120 N per 50 mm on PVC.
Q4. Can you weld a PVC window into a TPU bag?
Not reliably. PVC fuses by radio-frequency dielectric heating at 27.12 MHz, while TPU needs conducted heat from a hot wedge or hot air nozzle. A mixed bond can look acceptable and still peel at 40 to 60 N per 50 mm.
Q5. What thickness should a dry bag window be?
0.4 to 0.5 mm, matched to the shell within about 0.1 mm. Below 0.3 mm the panel scratches easily; above 0.6 mm it stops draping with the shell and the stiffness step concentrates every fold into the weld line.
Q6. Do clear windows crack in cold weather?
PVC ones can. General-purpose clear PVC starts to crack in a bend test near minus 15 °C, so a bag rolled closed at minus 12 °C is close to the limit. TPU films still pass at minus 35 °C and are the correct choice for cold markets.
Q7. How do I stop a window going sticky?
Choose TPU. Sticky panels are a PVC plasticiser migrating to the surface, accelerated by heat; a bag left in a 60 °C car boot loses plasticiser several times faster than one stored indoors, and the loss cannot be reversed.
Q8. Where should a window be placed on a dry bag?
Low on a front or side panel, clear of the roll fold line, with 10 mm radiused corners. The fold is the worst position because the panel is bent 180 degrees three times on every close, and square corners concentrate peel stress at one point.
Q9. How do you clean a clear window without scratching it?
Rinse with fresh water first, then wipe with a wet microfibre cloth and air dry. Never wipe a dry or salty panel, because the grit acts as an abrasive, and never use alcohol, acetone or screen cleaner, which leave a permanent milky bloom.
Q10. Does a window make a dry bag harder to recycle?
Yes, especially a PVC window in a TPU shell, because PVC contaminates and gels a TPU recycling stream above about 180 °C. Keeping both in one polymer family and window area under roughly 8% of the surface preserves most of the value.
Q11. Is aliphatic TPU worth the extra cost?
For bags sold into high-UV markets, yes. It is the only clear film that stays genuinely clear over years of sun because it lacks the aromatic groups that yellow, and the premium is usually 20 to 40% of the panel cost rather than of the whole bag.
Q12. How big can a window be before it weakens the bag?
Keep it under about 8% of the bag surface. Every centimetre of perimeter is a leak path, so a tall 18 x 24 cm window adds 84 cm of weld, while a horizontal 30 x 8 cm strip spreads the same area across a flatter, lower-stress zone.
Q13. Can a scratched window be polished out?
Generally no. Surface scratches in a 0.4 mm film are deeper than any practical polishing allowance, and heat polishing will distort the weld. Prevention is the only real option: rinse before wiping and keep the panel away from sand.
Q14. Will sunscreen damage a clear window?
It can. Some UV filters soften the surface of TPU and PVC on contact, leaving a hazy patch. Wipe the panel with fresh water at the end of a beach day rather than waiting until the end of a trip.
Q15. How do I test a window panel before approving a sample?
Run four checks: 300 hours of ISO 4892-3 UV with a delta E measurement, a low-temperature bend at the market minimum, a 30-minute immersion at one metre on three samples, and a peel test taken from production welds rather than from separate coupons.
Q16. Does a window affect how a roll-top closes?
It does if the panel crosses the fold line. Keep the window in the lower third of the bag so the roll folds shell fabric against shell fabric; a panel in the fold makes the closure stiffer and prints a crease into the film.
People also ask
What is a clear window on a dry bag for?
It lets you identify the contents without opening the roll-top, which matters when a bag is buried in a hatch or a hold. It is a functional panel, so clarity, weld integrity and UV stability all have to be specified, not just the look.
Are PVC windows bad for the environment?
They are the least recyclable option. PVC contaminates TPU and polyester recycling streams and releases acid gas if incinerated poorly, which is why most programmes moving to recycled content switch the window to TPU at the same time.
Why are some dry bag windows cloudy when new?
Usually because the film is EVA or a low-grade PVC with high inherent haze, or because the panel was welded at too low a temperature and the surface has partially fused. Haze above about 8% makes contents hard to identify.
How long does a clear TPU window last?
With shaded storage and fresh-water rinsing, a 0.4 mm aromatic TPU panel typically stays readable for five to eight years of weekend use, and an aliphatic panel longer. Direct sun and sand abrasion are what shorten it.
Can you replace a damaged window panel?
Only by cutting out the whole panel and welding a new one, because a patch over a damaged window doubles the haze and leaves the original weak perimeter in place. Most bags are cheaper to retire than to re-panel.
Do clear windows need UV stabilisers?
Yes. Both PVC and TPU panels rely on a hindered amine light stabiliser and a UV absorber in the film to reach 300 hours of accelerated exposure without visible colour shift, and the package is what separates a cheap panel from a good one.
